SMART Room System Setup And Maintenance Manual page 78

A P P E N D I X B
Resetting the room system to factory defaults
To reset the room system from the BIOS
1. Connect a USB keyboard to the Lync appliance.
2. Turn on the room system using the power switch located on the bottom of the interactive flat
panel.
Small room
N O T E
In large room installations, turn on both interactive flat panels.
3. Press the DELETE key.
The Lync appliance enters BIOS mode.
4. Browse to the Advanced tab
5. Select Recovery Function, and then press ENTER.
6. Set Image Recovery to Enabled.
7. Press ESC.
8. Browse to the Save & Exit tab.
9. Select Save Changes and Exit, and then select Yes.
The room system restarts, and the software is reset to factory defaults.
10. Complete the procedure in Configuring your room system's software on page 11.
72 smarttech.com/kb/170450
Medium room Large room (×2)
