C H A P T E R 3
Configuring your room system's software
3. Configure the interactive flat panels' on-screen display menus:
Room
Small (without
the table
microphone
upgrade kit)
Small (with the
table microphone
upgrade kit)
Medium
Large
N O T E
Completing the above steps configures the interactive flat panels' USB-video mapping, audio
settings, presence detection settings and other settings for use with SMART Room Systems.
In addition, completing the above steps disables the volume and input select controls on the
interactive flat panels' front control panels.
4. Continue to the next procedure.
14 smarttech.com/kb/170450
Procedure
a. Press MENU on the interactive flat panel's remote control.
b. Press the down arrow until you select the SETUP menu, and then
press SET.
c. Press the down arrow until you select Lync® ROOM RESET, and
then press SET.
d. Press MENU, press the up arrow until you select the AUDIO menu,
and the press SET.
e. Press the down arrow until you select AUDIO INPUT, press SET and
then select HDMI3/PC ANALOG.
f. Press MENU until the on-screen display menu closes.
a. Press MENU on the left interactive flat panel's remote control.
b. Press the down arrow until you select the SETUP menu, and then
press SET.
c. Press the down arrow until you select Lync® ROOM RESET, and
then press SET.
d. Press MENU until the on-screen display menu closes.
a. Press MENU on the interactive flat panel's remote control.
b. Press the down arrow until you select the OPTION menu, and then
press OK.
c. Press the down arrow until you select Lync® Room Reset, and then
press OK.
d. Press MENU until the on-screen display menu closes.
a. Press MENU on the left interactive flat panel's remote control.
b. Press the down arrow until you select the SETUP menu, and then
press SET.
c. Press the down arrow until you select Lync® ROOM RESET, and
then press SET.
d. Press MENU until the on-screen display menu closes.
e. Repeat steps a to d for the right interactive flat panel.
