C H A P T E R 1
Welcome
Depending on your room system, the microphones either are integrated with the camera or are
separate units that are typically located on the meeting room table.
N O T E
Large and medium rooms come with two table microphones. You can purchase additional table
microphones (see Table microphones on the next page).

Speakers

The speakers transmit audio from remote participants during a meeting. The room
system's audio-processing features eliminate echos and in-room audio feedback.
The speakers are installed on either side of the interactive flat panels.

Video connection harness for guest laptops

The video connection harness enables users to connect their laptops to the room system using either
VGA or HDMI connectors. When a user connects his or her laptop, the laptop's video output appears
on an interactive flat panel and is shared with remote participants.
The video connection harness's connectors are typically located on the meeting room table.
Table microphone upgrade kit
A table microphone upgrade kit is available for room systems for small rooms. This
upgrade kit enables you to use table microphones rather than the camera-integrated
microphones for specialized or challenging room configurations. The upgrade kit
includes two table microphones, an audio processor and accompanying cables.

Accessories

Accessories for the SMART Room System include the wall stand kit and table microphones.
N O T E
For accessory part numbers and ordering information, refer to the specifications (see Specifications
on page 7).
