C H A P T E R 5
Maintaining your room system
9. Press the red target with the tip of an interactive flat panel pen. Hold the tip at the center of the
target until the target turns green, and then lift the pen.
The target moves to the next location.
I M P O R T A N T
Hold the pen perpendicular to the screen.
N O T E
You can calibrate a target again by pressing the Keyboard button or the Right-click button on
the interactive flat panel's color select module.
10. Continue pressing targets until the calibration is complete.
A message appears stating that the calibration was successful, and then the orientation screen
appears.
11. Orient the interactive flat panel (see Orienting the interactive flat panels below).

Orienting the interactive flat panels

Typically, you need to orient the interactive flat panels during initial configuration only (see
Configuring SMART Settings on page 19). However, you might need to orient the interactive flat
panels again if the location of users' touch is misinterpreted (a pointer appears a distance from the
actual contact or on a different display than the one being touched).
I M P O R T A N T
To orient the interactive flat panels, you need the room system administrator account's user name
and password. You're unable to orient the interactive flat panels in user mode.
To orient an interactive flat panel
1. On the console, press Options, and then press Settings.
The Enter your credentials screen appears.
2. Type the room system administrator account's user name and password, and then press
Authenticate.
The room system restarts.
3. Type the room system administrator account's user name and password, and then press
ENTER.
The Settings screen appears.
