C H A P T E R 3
Configuring your room system's software

Logging on and configuring the displays

To log on and configure the displays
1. Type the administrator account's user name and password that you created in the previous
procedure, and then press ENTER.
The Lync appliance's desktop and the SMART end user license agreement appear.
2. Read the SMART end user license agreement, and then click Accept.
The Conferencing Microphone Configuration dialog box appears.
3. If you're configuring the software for a small room without the table microphone upgrade kit,
select Use the camera microphone, and then click OK.
OR
If you're configuring the software for a small room with the table microphone upgrade kit, a
medium room or a large room, select Use the table microphone, and then click OK.
I M P O R T A N T
You are unable to change this setting later, so ensure you select the correct option.
o
If you originally configured the software for a small room without the table microphone
o
upgrade kit and subsequently want to configure it for a small room with the table
microphone upgrade kit, you must set the room system to its factory defaults (see
Resetting the room system to factory defaults on page 71).
A dialog box prompting you to check the display settings appears.
4. Click OK.
Control Panel opens, and a second dialog box appears.
