C H A P T E R 6
Troubleshooting your room system

Locating power and status lights

Your room system's components have power and status lights, which you can use when resolving
common issues with the room system.
No. Component
1 Interactive flat panel
2 Interactive flat panel
3 Console
4 Camera
5 Camera
6 Camera
7 Microphones
8 Speakers
N O T E
The Lync appliance includes power and hard drive activity lights (not shown).
47 smarttech.com/kb/170450
Light
Power
Touch system status
Power and status
Video capture
Service
Microphone (if camera-integrated microphones used)
Microphone (if table microphones used)
Power
