A P P E N D I X A
Using the interactive flat panel on-screen display menu
Option
TREBLE
BASS
LINE OUT
HDMI3/PC LINE OUT
AUDIO INPUT
LEFT SPEAKER
RIGHT SPEAKER
AUDIO RESET
OSD
LANGUAGE
OSD TURN OFF
OSD H-POSITION
OSD V-POSITION
INFORMATION OSD
59 smarttech.com/kb/170450
Values Function
L50–R50 Sets the high frequency sound
L50–R50 Sets the low frequency sound
FIXED Sets the audio line out
VARIABLE
FIXED Sets the audio line out for the room
computer (HDMI3/PC)
VARIABLE
DPORT Sets the audio input source
USB
IN1
IN2
IN3
HDMI3/PC
ANALOG
HDMI3/PC
DIGITAL
ON Enables or disables the left
speaker
OFF
ON Enables or disables the right
speaker
OFF
[N/A] Resets all options in the AUDIO
menu to their default values
[Languages] Sets the on-screen display menu's
language
5–240 Sets the time of inactivity before
the on-screen display menu turns
off (in seconds)
0–100 Sets the horizontal position of the
on-screen display menu
0–100 Sets the vertical position of the
on-screen display menu
3–10 Specifies how long the information
menu displays when a user
OFF
changes the video input or presses
the DISPLAY button on the
remote control
Notes (if any)
This option isn't applicable to the
SMART Room System. Don't
change it from its default value.
This option isn't applicable to the
SMART Room System. Don't
change it from its default value.
Don't change this option from its
default value.
Don't change this option from its
default value.
Alternatively, you can press the
AUDIO INPUT button on the
remote control.
For small room systems without
the table microphone upgrade kit,
this option should be set to
HDMI3/PC ANALOG.
For small room systems with the
table microphone upgrade kit and
large room systems, this option
should be set to IN2.
Don't change this option from its
default value.
Don't change this option from its
default value.
This option isn't applicable to the
SMART Room System. Don't
change it from its default value.
