A P P E N D I X A
Using the interactive flat panel on-screen display menu

Small and large room on-screen display menu

Option
PICTURE MODE
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
TINT
COLOR
COLOR TEMPERATURE
COLOR
TEMPERATURE
RED
57 smarttech.com/kb/170450
Values Function
STANDARD Sets the picture mode
CINEMA/sRGB
SPORT
GAME
USER
AMBIENT
DYNAMIC
0–100 Sets the overall brightness of the
image and background
0–100 Sets the brightness of the image in
relation to the background
0–100 Sets the image sharpness
0–100 Sets the level of brightness in the
darkest parts of the image
0–100 Sets the image tint
0–100 Sets the image color depth
NORMAL Sets the color temperature
WARM
USER
COOL
0–100 Sets the amount of red in the
Notes (if any)
Select USER to customize
brightness, contrast, sharpness
and other PICTURE options.
Select AMBIENT to set brightness
based on the illuminance level of
the room and to customize all other
PICTURE options.
Select one of this option's other
values to set brightness, contrast,
sharpness and other PICTURE
options to default values.
Alternatively, you can press the
PICTURE MODE button on the
remote control.
You can modify this option only if
you select USER in
PICTURE MODE.
You can modify this option only if
you select USER or AMBIENT in
PICTURE MODE.
You can modify this option only if
you select USER or AMBIENT in
PICTURE MODE.
You can modify this option only if
you select USER or AMBIENT in
PICTURE MODE.
You can modify this option only if
you select USER or AMBIENT in
PICTURE MODE.
You can modify this option only if
you select USER or AMBIENT in
PICTURE MODE.
Select USER to customize the
amount of red, green and blue in
the image.
Select one of this option's other
values to set the amount of red,
green and blue in the image to
default values.
You can modify this option only if
you select USER in
COLOR TEMPERATURE.
