Summary of Contents for SMART UF45-680
- Page 1 Service Parts Diagrams For Model: UF45-680 UF45-660...
- Page 2 ServiceParts@smarttech.com www.smarttech.com © 2009 SMART Technologies ULC. All rights reserved. SMART Board, smarttech, Unifi and the SMART logo are trademarks or registered trademarks of SMART Technologies ULC in the U.S. and/or other countries. All other third-party product and company names are for identification purposes only and...
- Page 3 Service Parts Diagrams for the UF45-680 and UF45-660 Identifying Your Product Using the Serial Number ..............1 Ordering Parts ..........................1 Unifi 45 Mount and Documentation .................... 2 Unifi 45 Mirror Assembly (Part No. 20-00906-20) ............... 3 Unifi 45 Connection Cables, Hardware and Projector Accessories ........4...
- Page 4 Service Parts Diagrams for the UF45-680 and UF45-660...
- Page 5 For specific technical and pricing enquiries in regards to these diagrams please contact our service parts department. Pricing is also available on-line via the SOURCE website (source.smarttech.com). E-mail: serviceparts@smarttech.com Phone: 1.888.42.SMART International: +1.403.245.0333 Service Parts Diagrams for the UF45-680 and UF45-660...
- Page 6 Cover, boom interface 51-00661-21 Plate, projector 20-00925-22 Kit, documentation, for models UF45-680 and UF45-660 NOTE: Includes mounting templates, installation guide and user guide. 20-00995-20 Kit, projector lock 52-00482-20 Access door, head, Unifi 45 Service Parts Diagrams for the UF45-680 and UF45-660...
- Page 7 Item Part No. Description 30-01117-20 Nut, M8, locking, nylon 30-01126-20 Screw, M8 × 60 mm, hex, socket head 30-01130-20 Knob, M6 30-00946-20 Screw, M4 × 6 mm, Phillips, pan head 30-01131-20 Spring Service Parts Diagrams for the UF45-680 and UF45-660...
- Page 8 Battery, AA 20-00904-20 Kit, assembly hardware 20-00907-21 Kit, mounting hardware 03-00122-20 Remote control 51-00662-21 Limit strap NOTE: Contact Technical Support to discuss replacement. Not shown 01-00247 Replacement Lamp for Unifi 45 Projector Service Parts Diagrams for the UF45-680 and UF45-660...
