SDM-300L3 Satellite Modem
Options
Entering Access Codes from the Remote Control Port
Verify Upgrade
1. Establish remote communication with the unit. Display will show REMOTE
MODE (if applicable).
2. Enter the following commands as needed to enable the option related to each
board:
Main Board: <x/CCMD_code
Overhead board: <x/CCOD_code
Mux/Demux Board: <x/CCMX_code
TX-Reed-Solomon: <x/CCTR_code
RX-Reed-Solomon: <x/CCRR_code
3. The modem should re-initialize and boot up to the factory default settings.
Note: If the unit is an SDR-54/54A, the power should be cycled to re-initialize
the unit and enable the option(s).
1. Press [CLEAR] to return to the Main menu.
2. Use [←] and [→] to select Function Select Utility menu.
3. Press [ENTER].
4. Use [←] and [→] to select Utility Modem Type menu.
5. Press [ENTER].
6. Use [←] and [→] to select Modem Options menu.
7. Press [ENTER].
8. Use [←] and [→] to scroll through features. Visually check selected features
for a "+" sign. If a "+" sign is evident, the upgrade is completed.
9 If upgrade is incorrect, the menu display will exhibit "WRONG CODE
ENTERED." Repeat procedures. Contact Comtech EF Data Customer
Support personnel for further instructions, if the error message remains.
x = address
code = 20 digit configuration code
