SDM-300L3 Satellite Modem
Front Panel Operation
FUNCTION SELECT: CONFIGURATION:INTERFACE:
DROP FORMAT (CONDITIONAL)
IMPORTANT
Upon entry, the current drop data channel signal is displayed. Press [↑] or [↓] to make the
selection. Press <ENTER> to execute the change.
This configuration is used to select the desired drop data channel signaling. The choices
are:
•
•
•
•
•
•
•
•
•
DROP FORMAT
This menu is only available when the optional D&I have been selected
for Modem Type in the Utility menu and the Overhead Card is installed.
E1_CCS (E1 Common Channel Signaling)
E1-CAS (E1 Channel Associated Signaling)
E1_IBS (E1 International Business Service)
E1_31_TS (E1 No Multiframe Sync Alignment)
T1 (T1 Data)
T1_IBS (T1 International Business Service)
T1_ESF (T1 Extended Super Frame)
T1_ESF_S (Special Signaling)
T1_S (Special Signaling)
T1
4–38
Revision 1
MN/SDM300L3.IOM
