SDM-300L3 Satellite Modem
Front Panel Operation
FUNCTION SELECT: UTILITY: SYSTEM: YEAR DISPLAY
Displays the year in either 2-digits or 4-digits.
To change the remote address, press <ENTER>. Press [↑] or [↓] to make the selection.
Press <ENTER> to execute the change.
FUNCTION SELECT: UTILITY: SYSTEM: TEST MODE STATUS
Test mode status indicator. The following modem test points are listed and display a "+"
when a test mode is active:
To view the test modes, press <ENTER>. Press [↑] or [↓] to make the selection.
FUNCTION SELECT: UTILITY: SYSTEM: LAMP TEST
Lamp test function. Press <ENTER> to turn the front panel indicators on for 3 seconds.
YEAR DISPLAY
TEST MODE STATUS
_ _ _ _ _ _ _ _
•
RS CORR OFF
•
INTRFC LOOP BACK
•
B-BAND LOOP BACK
•
CARRIER MODE
•
RX 2047 Pattern
•
TX 2047 Pattern
•
IF LOOP BACK
LAMP TEST ??
PRESS ENTER
2 - DIGIT
(requires Overhead card)
(requires Overhead card)
4–113
Revision 1
MN/SDM300L3.IOM
