SDM-300L3 Satellite Modem
Front Panel Operation
FUNCTION SELECT: CONFIGURATION: LOCAL AUPC:
MAXIMUM POWER (CONDITIONAL)
IMPORTANT
Programs the maximum power level of the AUPC. The maximum power level can range
from 0 to -40 dBm, in 0.5 dBm steps.
FUNCTION SELECT: CONFIGURATION: LOCAL AUPC:
TARGET EB/NO (CONDITIONAL)
IMPORTANT
Programs the E
16.0 dB, in 0.1 dB steps
MAXIMUM POWER
-5.0 dBm
Conditional: This menu is displayed when Local Modem AUPC = ON
located under the Utility: Modem Type menu.
TARGET EB/NO
6.0 dB
Conditional: This menu is displayed when Local Modem AUPC = ON
located under the Utility: Modem Type menu.
Manufacturer does not recommend a setting greater than 15.5 dB.
/N
target set point. The E
b
0
/N
target set point ranges from 3.2 to
b
0
4–48
Revision 1
MN/SDM300L3.IOM
