SDM-300L3 Satellite Modem
Front Panel Operation
FUNCTION SELECT: CONFIGURATION: FLEX MUX:
RX CHAN #1 MODE
RECEIVE CHANNEL 1 MODE: D&I ENABLED, T1/E1 ENABLED, or DISABLED
Normal D&I/G.703 menus are operational.
FUNCTION SELECT: CONFIGURATION: FLEX MUX:
RX CHAN #1 DATA RATE
RECEIVE CHANNEL 1 DATA RATE:
Note: DR command is not displayed if DISABLED was selected for MODE.
FUNCTION SELECT: CONFIGURATION: FLEX MUX:
RX CHAN #2 MODE
RECEIVE CHANNEL 2 MODE: ADPCM ENABLED or ADPCM DISABLED
Allows ADPCM 32Kbps operation.
FUNCTION SELECT: CONFIGURATION: FLEX MUX:
RX CHAN #3 MODE
RECEIVE CHANNEL 3 MODE:
SYNC
RX CHAN #1 MODE
D&I ENABLED
RX CHAN #1 DR
64.0 Kbps
RX CHAN #2 MODE
ADPCM DISABLED
RX CHAN #3 MODE
SYNC RS422
4–57
1544.0 Kbps or 2048.0 Kbps for bypass,
N * 64.0 Kbps for D&I
ASYNC RS232, SYNC RS232, ASYNC RS422,
RS422,AUPC, or DISABLED
Revision 1
MN/SDM300L3.IOM
