SDM-300L3 Satellite Modem
Front Panel Operation
FUNCTION SELECT: UTILITY: DEMODULATOR:
RX-RS N/K DEEP (CONDITIONAL)
IMPORTANT
N/K is status only.
Deep is interleaver depth and is programmable to a depth of 4, 8, or 16.
FUNCTION SELECT: UTILITY: DEMODULATOR:
RX IESS-310 MODE (CONDITIONAL)
IMPORTANT
Selection of On or Off used for 8-PSK 2/3 with Reed-Solomon.
FUNCTION SELECT: UTILITY: DEMODULATOR:
RX IESS-315 MODE (CONDITIONAL)
IMPORTANT
RX-RS N/K DEEP
225/205
Conditional: This menu is active only when Reed-Solomon (RS) is
installed and RS Option is On (under Configuration: Demodulator).
RX IESS-310 MODE
Conditional: Note: Only available when the 8-PSK option is selected and
Reed-Solomon option is installed and selected.
RX IESS-315 MODE
Conditional: Note: Only available when the turbo is installed.
8
OFF
OFF
4–98
Revision 1
MN/SDM300L3.IOM
