SDM-300L3 Satellite Modem
Front Panel Operation
FUNCTION SELECT: CONFIGURATION: FLEX MUX:
TX CHAN #3 MODE
TX CHANNEL 3 MODE:
RS422,
Async communications are fixed at 10 bits per word.
AUPC can be enabled only on either Tributary 3 or Tributary 4. The AUPC channel
operates at 600 bps.
FUNCTION SELECT: CONFIGURATION: FLEX MUX:
TX CHAN #3 DATA RATE
SYNC RS422: 0.6 to 4000.0 kbps
All other modes: 0.6 to 64.0 kbps
Channels 3 and 4 data rates are in steps of 100 bps.
Note: DR command is not displayed if AUPC or DISABLED were selected for MODE.
FUNCTION SELECT: CONFIGURATION: FLEX MUX:
TX CHAN #3 PHASE
TX CHANNEL 3 PHASE: NRM or INV (for both clock and data phase)
Note: PHASE command is not displayed if AUPC or DISABLED were selected for
MODE.
TX CHAN #3 MODE
SYNC RS422
ASYNC RS232, SYNC RS232, ASYNC RS422, SYNC
AUPC, or DISABLED
TX CHAN #3 DR
64.0 Kbps
TX CHAN #3 PHASE
CLK:NRM DATA:NRM
