SDM-300L3 Satellite Modem
Front Panel Operation
FUNCTION SELECT: STORED FLTS/ALMS: MODULATOR
Displays the stored date and time of a fault or alarm, such as:
•
•
•
•
•
•
•
•
•
•
FUNCTION SELECT: STORED FLTS/ALMS: DEMODULATOR
Displays the stored date and time of a fault or alarm, such as:
•
•
•
•
•
•
•
•
MODULATOR
STORED TIME/DATE
IF SYNTHESIZER
DATA CLOCK SYN
I CHANNEL
Q CHANNEL
AGC LEVEL
MODEM REF ACT
MODEM REF PLL
MODULE
CONFIGURATION
ODU
DEMODULATOR
STORED TIME/DATE
CARRIER DETECT
IF SYNTHESIZER
I CHANNEL
Q CHANNEL
BER THRESHOLD
MODULE
CONFIGURATION
LNB CURRENT
X
X
4–75
Revision 1
MN/SDM300L3.IOM
