SDM-300L3 Satellite Modem
Front Panel Operation
4.6.1.4
FUNCTION SELECT: CONFIGURATION: LOCAL AUPC
(CONDITIONAL)
IMPORTANT
The menu is available in several modes:
Self-Monitoring AUPC with 1
Modem:
Remote AUPC between 2
Modems:
Press <ENTER> to review or edit sub-menus that follow. The selections are On or Off.
FUNCTION SELECT: CONFIGURATION: LOCAL AUPC:
AUPC ENABLE (CONDITIONAL)
IMPORTANT
Programs the AUPC On or Off.
Upon entry, the current status is displayed. Press [↑] or [↓] to make the selection. Press
<ENTER> to execute the change.
CONFIGURATION
LOCAL AUPC
Conditional: This menu is displayed when Local Modem AUPC = ON
located under the Utility: Modem Type menu.
In this mode ASYNC is not used. This does not require the
Overhead card or the Reed-Solomon cards.
The optional Overhead card is installed and the Modem Type
is ASYNC located under the Utility: Modem Type menu. In this
mode ASYNC is available or,
The optional Reed-Solomon cards are installed and the
Modem Type is AUPC located under Utility: Modem Type
menu.
AUPC ENABLE
Conditional: This menu is displayed when Local Modem AUPC = ON
located under the Utility: Modem Type menu.
OFF
4–46
Revision 1
MN/SDM300L3.IOM
