SDM-300L3 Satellite Modem
Front Panel Operation
4.6.6.2
FUNCTION SELECT: UTILITY: MODULATOR
Select information to view using the [←] [→] arrow keys, then press ENTER.
FUNCTION SELECT: UTLITY: MODULATOR:
ASSIGN TRANSMIT FILTERS
Note: The setting in the following menus, changes the settings in the menus that appear
under the Configuration: Modulator menus.
UTILITY
MODULATOR
TX-A
QPSK 1/2
64.000 Kbps
TX-B
QPSK 1/2
128.000 Kbps
TX-C
QPSK 1/2
256.000 Kbps
TX-D
QPSK 1/2
512.000 Kbps
TX-V
QPSK 1/2
38.400 Kbps
4–84
Revision 1
MN/SDM300L3.IOM
