Ethernet Port
LED Colour Activity
•
ACT Green
•
•
•
100M Orange
•
Settings/Sensor Port
LED Colour Activity
•
UPS Green
•
Data
•
•
RS232 Orange
•
•

2.3 Installation in the UPS

The Network Management Card (Network-MS) is "hot-swappable". It can be installed in all UPSs of the EATON
Pulsar series or EATON Powerware series equipped with a Minislot without having to shut it down.
On the UPS, remove the cover from the Minislot
•
Insert and tighten the card's retaining screws
•
Connect the ETHERNET cable
•
Wait 2min 30s. The card is completely operational when the green UPS Data LED flashes continuously.
•
Network Management Card
Description
Off Card not connected to the network.
•
Card connected to the network but without
•
On
activity
Flashing Port is active in receiving / transmission
•
Off Port operating at 10Mbits/s.
•
On Port operating at 100Mbits/s.
•
Description
Off Card startup in progress.
•
On Communication with UPS in progress
•
Normal operation. Communication with the UPS
•
Flashing
is operational
Off Configuration menu is active
•
On Normal operation. Configuration menu is
•
deactivated
Flashing Communication with the Environment Sensor
•
(option).
