RealPresence®Collaboration Server (RMX) 2000 Hardware Guide
RMX 2000 Front Panel LEDs
Component
SLOT (1-4) LEDs
ShMG LEDs
STANDBY LED

RTM ISDN Card

The following LEDs appear on the RTM ISDN Card.
RTM ISDN LEDs
Function Name
LAN 1 LEDs 1 Gb
LNK
PRI LEDs
ShMC LED HS
Polycom, Inc.
LED Name LED Color
1Gb (1-4) Amber
LNK (1-4) Green
ERR Red
ACT Amber
RDY Green
HS Blue
Green
LED Color
Amber
Green
OFF
Green
Red
Blue
Description
ON with a 1Gb online connection, flickers with Packet
activity.
ON with an active network connection, flickers with Packet
activity.
ON - Major error on RTM card.
Flashes - During system startup.
ON - Packet flow to and from the MCU chassis.
Flashes - During system startup.
ON - RTM IP card has successfully completed startup.
Flashes - During system startup.
Hot swap not supported.
OFF - Normal.
Flashes for a second during initial power up.
When the user in the RMX Manager/ RealPresence
Collaboration Server Client presses the System Shut Down
(red) button in the Hardware Monitor tool bar, the system
should enter a standby mode and the LED turns ON. Only
the media and control unit cards are in a standby mode.
Shelf Manager remains active.
Turn the system OFF/ON to exit the standby mode.
Description
ON when 1Gb connection is online, flickers with Packet
activity.
ON with an active network connection, flickers with Packet
activity.
Span x not in use.
Span x is OK.
Span x red alarm (LOS - Loss of Signal)
OFF - Normal.
38
