RealPresence®Collaboration Server (RMX) 2000 Hardware Guide
RMX 2000 Component Description
Component
Multi Processor Module
(MPMx) Card
Multi Processor Module
(MPMRx) Card

RealPresence Collaboration Server (RMX) 2000 Rear Panel

The RMX 2000 rear panel contains the RTM IP card and optionally, the RTM LAN and RTM ISDN card. The
RTM IP card must be located on the bottom slot in the rear of the RMX 2000. In addition, the rear panel
houses the main power switch, AC inlet, a circuit breaker, and additional communications ports.

RTM IP

The RTM IP card provides system management based on the ATCA standard and connects to the
backplane. It controls and monitors the system fans and regulates power supply. This card contains an
Ethernet Switch that manages the network of the system, routes data between the cards and components
of the system and provides connectivity to external IP networks.
The RTM IP card connections include:
● 3 LAN ports
● 10/100Mb ShMG port (Future Use)
● 1 Serial port (Future Use)
● 1 USB port
Polycom, Inc.
Description
The MPMx cards, perform the various RTP, audio and video processing
functions on the RMX 2000 unit. TI processors are at the core of each MPMx
card which are available in the following assemblies:
• MPMx -S
• MPMx -D
Notes:
• The MPMx card(s) can only work with software version 7.0 or later. Ensure
that software appropriate to the MCU hardware configuration is installed in the
MCU.
• The MPMx card can work only with a new environmentally friendly D or E -type
chassis and is disabled when inserted in a C-type chassis.
The MPMRx cards, perform the various RTP, audio and video processing
functions on the RMX 2000 unit. TI processors are at the core of each MPMx
card which are available in two assemblies:
• MPMRx -S
• MPMRx -D
Notes:
• An MPMRx card on the front of the RMX must always be seated or connected
opposite to either an RTM LAN or RTM ISDN card on the rear of the chassis.
• The MPMRx card(s) can only work with software version 8.3 or later. Ensure
that software appropriate to the MCU hardware configuration is installed in the
MCU.
• The MPMRx card can work only with a new environmentally friendly D or
E-type chassis and is disabled when inserted in a C-type chassis.
