HP ProLiant BL465c G7 Server Blade

The HP ProLiant BL465c G7 Server Blade is used as a control node, a utility node, and a compute node in
HP Cluster Platform configurations.
HP ProLiant BL465c G7 Server Blade documentation
For server blade-specific information, see the server blade documentation:
•
For a complete list of features and specifications, see the HP ProLiant BL465c Generation 7 (G7) Server
Blade QuickSpecs on the HP website
(http://h18004.www1.hp.com/products/quickspecs/13654_na/13654_na.html).
•
For installation and service information, see the HP ProLiant BL465c G7 Server Blade User Guide and
the HP ProLiant BL465c G7 Server Blade Maintenance and Service Guide on the HP website
(http://www.hp.com/support/manuals).
Under BladeSystem, select BladeSystem Server Blades, and then select HP ProLiant BL465c G7 Server
series.
Front panel components (BL465c G7)
Item
1
2
3
4
5
6
* The SUV connector and the HP c-Class Blade SUV cable are for some server configuration and diagnostic procedures.
Front panel LEDs (BL465c G7)
Description
Serial label pull tab
SUV connector*
Server blade release button
Power On/Standby button
Server blade release lever
Hard drive bays
