HP Cluster Platform Hardware Kits v2010 Installation Manual
Procurve 5406zl cx4 cable management brackets installation guide
Hide thumbs
Also See for Cluster Platform Hardware Kits v2010:
- Installation manual (20 pages) ,
- Hardware (4 pages) ,
- Installation manual (10 pages)
Related Manuals for HP Cluster Platform Hardware Kits v2010
Summary of Contents for HP Cluster Platform Hardware Kits v2010
- Page 1 HP Cluster Platform ProCurve 5406zl CX4 Cable Management Brackets Installation Guide HP Part Number: 5991-7986 Published: June 2007...
- Page 2 © Copyright 2007 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
-
Page 3: Table Of Contents
Table of Contents 1 Preparing for Installation....................9 1.1 Audience............................9 1.2 Documentation Resources.........................9 1.3 Kit Description..........................9 1.4 Kit Contents............................9 1.5 Required Resources.........................10 2 Installing the Cable Management Brackets...............11 2.1 Cable Routing Options........................12 2.2 Removing the Interconnect for Servicing..................13 Table of Contents... -
Page 5: List Of Figures
List of Figures Cable Management Brackets......................9 Attaching the Cable Management Brackets..................11 Cable Routing Options........................12... -
Page 7: List Of Tables
List of Tables Fasteners............................10... -
Page 9: Preparing For Installation
1 Preparing for Installation 1.1 Audience This guide is intended for HP service representatives and other persons trained to install hardware options in the HP 10000 series racks. Such persons are expected to understand the hazards of working in this environment and to take suitable precautions to minimize danger to themselves and others. -
Page 10: Required Resources
Right side cable management bracket (left side not shown) Note that the top channel for both the right and left brackets is narrower than the rest of the channels (right side shown). Note: The right bracket is shown in Figure 1-1. -
Page 11: Installing The Cable Management Brackets
2 Installing the Cable Management Brackets The location of the brackets depends on the rack position occupied by the interconnect. The interconnect in an HP Cluster Platform solution is typically installed in the lower “U” locations of the rack. To install the cable management brackets, follow these steps: Determine the cable management brackets installation locations by aligning the cable management bracket's mounting flange rack-mount holes with the flange rack-mount holes in the mounting ears (see callout 6 in... -
Page 12: Cable Routing Options
The following list describes the callouts shown in Figure 2-1: ProCurve 5406zl interconnect 10K rack right rear rail M6 x 16 mm mounting screw (two for each side used with two cage nuts) Cable management brackets ProCurve 5406zl rackmount bracket (left side shown) Left side ProCurve 5406zl interconnect mounting ear Important: The ProCurve 5406zl interconnect mounting ears are turned 180 degrees and point toward the... -
Page 13: Removing The Interconnect For Servicing
2.2 Removing the Interconnect for Servicing Bring the component to an appropriate state for removal, and put the rack cabinet into a safe and stable state for component removal. You must ensure that you can reach the component easily and handle it safely. Remove the interconnect as follows: Switch off the power supply from the rack's power distribution unit and disconnect the interconnect's power cable(s). - Page 14 *5991-7986* Printed in the US...
