HP Cluster Platform Cabling Tables v2010 Overview page 40

Item Description
Systems Insight Display
3
Hard drive bays
4
SATA optical drive bay
5
Video connector
6
USB connectors (2)
7
Front panel LEDs and buttons (DL385 G7)
Item Description
UID LED button
1
Health LED
2
Power On/Standby button
3
and system power LED
Rear panel components (DL385 G7)
Item Description
PCI slot 5
1
PCI slot 6
2
PCI slot 4
3
PCI slot 2
4
Status
Blue = Activated
Flashing blue = System being remotely managed
Off = Deactivated
Green = Normal
Flashing amber = System degraded
Flashing red = System critical
Green = System on
Flashing green = Waiting for power due to group power capping
Amber = System shut down but power still applied
Off = Power cord not attached or power supply failure
Color
—
—
—
—
HP ProLiant servers (rack) 40
