The PCIe x16 riser supports a maximum power of 150W with an HP power cable. The cable supplied
with the riser must be used for PCIe card wattages greater than 75W.

HP ProLiant DL380 G7 Server

The HP ProLiant DL380 G7 Server is used as a control node in HP Cluster Platform configurations.
HP ProLiant DL380 G7 Server documentation
For server-specific information, see the server documentation:
•
For a complete list of features and specifications, see the HP ProLiant DL380 Generation 7 (G7)
QuickSpecs on the HP website
(http://h18004.www1.hp.com/products/quickspecs/13595_na/13595_na.html).
•
For installation and service information, see the HP ProLiant DL380 G7 Server User Guide and the HP
ProLiant DL380 G7 Server Maintenance and Service Guide on the HP website
(http://www.hp.com/support/manuals).
Under servers, select ProLiant ML/DL and TC series servers, and then select HP ProLiant DL380 G7
Server series.
Front panel components (DL380 G7)
•
SFF hard drive model
Item Description
Quick release levers (2)
1
Systems Insight Display
2
HP ProLiant servers (rack) 23
