Hp Proliant Dl585 G6 Server - HP Cluster Platform Cabling Tables v2010 Overview

PCI expansion slot definitions (DL385 G7)
Always install an InfiniBand PCIe HCA in slot 1 of this server.
Secondary (slot -
form factor)
4 - FL/FH
5 - LP
6 - LP
Notes:
•
"Primary" denotes the risers are installed in the primary riser connector.
•
"Secondary" denotes the risers are installed in the secondary riser connector.
•
Installing the risers listed in the table above in either the primary or secondary riser connectors
determines the form factor of the PCI cards supported by those risers.
•
FL/FH denotes full-length, full-height. HL/FH denotes half-length, full-height. LP denotes low profile.
•
The PCIe2 x16 riser supports a maximum power of 225W with an HP power cable. This cable must be
used for PCIe card wattages greater than 75W.

HP ProLiant DL585 G6 Server

The HP ProLiant DL585 G6 Server is used as a control node, utility node, or compute node in HP Cluster
Platform configurations.
HP ProLiant DL585 G6 Server documentation
For server-specific information, see the server documentation:
•
For a complete list of features and specifications, see the HP ProLiant DL585 Generation 6 (G6)
QuickSpecs on the HP website
(http://h18004.www1.hp.com/products/quickspecs/13373_na/13373_na.html).
•
For installation and service information, see the HP ProLiant DL585 G6 Server User Guide and HP
ProLiant DL585 G6 Server Maintenance and Service Guide on the HP website
(http://www.hp.com/support/manuals).
Primary (slot - PCIe2 riser slot
form factor) description
1 - FL/FH PCIe2 x16
(8,4,2,1)
2 - HL/FH PCIe2 x8 (4,2,1) PCIe2x16
3 - HL/FH PCIe2 x8 (4,2,1) —
PCIe2 riser slot PCIe2 x16
description riser slot
description
PCIe2 x16 PCIe2 x16
(8,4,2,1) (16,8,4,2,1)
—
(8,4,2,1)
—
PCIe2/PCI-X
riser slot
description
PCI-X 64 bit/100
MHz
PCI-X 64 bit/100
MHz)
PCIe2 x8
(8,4,2,1)
HP ProLiant servers (rack) 42
