Front panel components (DL170e G6)
The HP Cluster Platform supports the following three models of the HP ProLiant DL170e G6 Server:
•
Four-node server with 8-bay LFF hard drive cage
Item
Description
LFF hard drive bays, populated (8)
1
Rack-mounting thumbscrews (2)
2
•
Four-node server with 16-bay SFF hard drive cage
Item
Description
SFF hard drive bays, populated (16)
1
Rack-mounting thumbscrews (2)
2
•
Four-node server with 24-bay SFF hard drive cage
HP ProLiant servers (rack) 13
