HP ProLiant BL2x220c G6 Server Blade

The HP ProLiant BL2x220c G6 Server Blade is used as a control node, a utility node, and a compute node
in HP Cluster Platform configurations.
HP ProLiant BL2x220c G6 Server Blade documentation
For server blade-specific information, see the server blade documentation:
•
For a complete list of features and specifications, see the HP ProLiant BL2x220c Server Blade
QuickSpecs on the HP website
(http://h18004.www1.hp.com/products/quickspecs/13294_na/13294_na.html).
•
For installation and service information, see the HP ProLiant BL2x220c G6 User Guide and the HP
ProLiant BL2x220c G6 Server Maintenance and Service Guide on the HP website
(http://www.hp.com/support/manuals).
Under BladeSystem, select BladeSystem Server Blades, and then select HP ProLiant BL2x220c G6
Server series.
Front panel components (BL2x220c G6)
Item Description
Server B Power On/Standby button
1
Server B serial label pull tab
2
Server blade release lever
3
Server A serial label pull tab
4
Server A Power On/Standby button
5
