Item Description
Fan 5 power LED
12
Fan 6 power LED
13
PCI expansion slot definitions (SL390s G7)
The HP ProLiant SL390s 1U Server (half width) has one available low-profile x16 PCIe2 slot.
The HP ProLiant SL390s 2U Server (half width) has one low-profile x8 PCIe2 slot and three x16 PCIe2 slots
for internal GPU support (up to 22.5W).

HP ProLiant Scalable Servers (AMD Opteron)

Several AMD Opteron servers are supported in HP Cluster Platform solutions. This section presents
information for the HP ProLiant servers that are used in HP Cluster Platform solutions only. The content in this
section includes the following additional information for the ProLiant AMD Opteron servers:
•
Front and rear views
•
InfiniBand HCA PCI slot assignment
•
Specific cable management instructions, if necessary
•
HP Cluster Platform specific maintenance instructions, if applicable
HP SL series-based Cluster Platforms require the use of the HP 10000 Series 1200mm Deep Rack. For more
information, see the HP website
(http://h18004.www1.hp.com/products/servers/proliantstorage/racks/1200series/index.html).

HP ProLiant SL165z G7 Server

The HP ProLiant SL165z G7 Server is used as a control node and a compute node in HP Cluster Platform
configurations.
HP ProLiant SL165z G7 Server documentation
For server-specific information, see the server documentation:
•
For a complete list of features and specifications, see the HP ProLiant SL165z G7 Server QuickSpecs on
the HP website (http://h18004.www1.hp.com/products/quickspecs/13542_na/13542_na.html).
•
For installation and service information, see the HP ProLiant SL1000/6000 Scalable System User
Guide and the HP ProLiant SL165z G7 Server Maintenance and Service Guide on the HP website
(http://www.hp.com/support/manuals).
Under servers, select ProLiant ML/DL and TC series servers, and then select HP ProLiant SL165z G7
Server series.
Status
Off—Normal
Amber—Fan has failed.
Off—Normal
Amber—Fan has failed.
HP ProLiant servers (scalable) 60
