Hp Proliant Dl385 G7 Server - HP Cluster Platform Cabling Tables v2010 Overview

•
FL/FH denotes full-length, full-height. HL/FH denotes half-length, full-height. LP denotes low profile.
•
The PCIe x16 riser supports a maximum power of 225W with an HP power cable. This cable must be
used for PCIe card wattages greater than 75W.

HP ProLiant DL385 G7 Server

The HP ProLiant DL385 G7 Server is used as a control node and utility node in HP Cluster Platform
configurations.
HP ProLiant DL385 G7 Server documentation
For server-specific information, see the server documentation:
•
For a complete list of features and specifications, see the HP ProLiant DL385 Generation 7 (G7)
QuickSpecs on the HP website
(http://h18004.www1.hp.com/products/quickspecs/13594_na/13594_na.pdf).
•
For installation and service information, see the HP ProLiant DL385 G7 Server User Guide and HP
ProLiant DL385 G7 Server Maintenance and Service Guide on the HP website
(http://www.hp.com/support/manuals).
Under servers, select ProLiant ML/DL and TC series servers, and then select HP ProLiant DL385 G7
Server series.
Front panel components (DL385 G7)
Item Description
Quick release levers (2)
1
Serial number label
2
HP ProLiant servers (rack) 39
