HP ProLiant DL165 G6 Server documentation
For server-specific information, see the server documentation:
•
For a complete list of features and specifications, see the HP ProLiant DL165 Generation 6 (G6)
QuickSpecs on the HP website
(http://h18004.www1.hp.com/products/quickspecs/13367_na/13367_na.pdf).
•
For installation and service information, see the HP ProLiant DL100 Series Server User Guide and the HP
ProLiant DL165 G6 Server Maintenance and Service Guide on the HP website
(http://www.hp.com/support/manuals).
Under servers, select ProLiant ML/DL and TC series servers, and then select HP ProLiant DL165 G6
Server series.
Front panel components (DL165 G6)
Item Description
Optical drive
1
Serial label pull tab
2
Front USB connector (2)
3
Rack mounting thumbscrews (2)
4
Hard drive bays (4)
5
Front panel LEDs and buttons (DL165 G6)
Item Description
Optical drive activity LED
1
Status
Flashing green = Ongoing drive activity
