For installation and service information, see the HP ProLiant BL280c Server Blade User Guide and the
HP ProLiant BL280c G6 Server Blade Maintenance and Service Guide on the HP website
(http://www.hp.com/support/manuals).
Under BladeSystem, select BladeSystem Server Blades, and then select HP ProLiant BL280c G6 Server
series.
Front panel components (BL280c G6)
Item
Description
Serial label pull tab
1
HP c-Class Blade SUV Cable connector
2
Release button
3
Server blade release lever
4
HP ProLiant BL c-Class Server Blades 71
