Front panel LEDs and buttons (SL2x170z G6)
The table below describes LEDs and buttons for one server only. Each server contains the same LEDs and
buttons in the same orientation.
Item Description
UID LED/button
1
Health LED
2
Power button/LED
3
NIC activity LED
4
NIC speed LED
5
Rear panel components, LEDs, and buttons (2xSL170z G6)
Item Description
RJ-45 connector
1
UID LED/button
2
Power supply cable connector 1
3
Status
Blue = Identification
Flashing blue = The system is being remotely managed.
Off = Deactivated
Red = Critical system failure detected.
Amber = The system is degraded.
Green = The system is powered on, and no failure is detected.
Off = The system is off, and no failure was detected prior to system
power down.
Green = Normal
Amber = The server is powered off or is in a hibernation state with AC
power.
Red = Critical error
Flashing green = Network data activity exists.
Off = No network data activity exists, or no network connection exists.
Green = The LAN connection is using a GbE link.
Amber = The LAN connection is using a 10 Mbps/100 Mbps link.
Off = No LAN connection exists.
HP ProLiant servers (scalable) 53
