32579B
3.4.18 Debug Monitoring Interface Signals
Signal Name Ball No.
FPCICLK B18
F_AD7 A18
F_AD6 A20
F_AD5 C19
F_AD4 C18
F_AD3 C20
F_AD2 D20
F_AD1 A21
F_AD0 C21
F_C/BE3# C17
F_C/BE2# D17
F_C/BE1# B17
F_C/BE0# D21
F_FRAME# A22
F_IRDY# B20
F_STOP# U29
F_DEVSEL# V31
F_GNT0# U31
F_TRDY# U30
INTR_O D22
SMI_O B21
3.4.19

JTAG Interface Signals

Signal Name Ball No.
TCK E31
TDI F29
68
Type Description
O Fast-PCI Bus Monitoring Signals. When enabled, this
group of signals provides for monitoring of the internal
Fast-PCI bus for debug purposes. To enable, pull up
O
FPCI_MON (ball A4).
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O CPU Core Interrupt. When enabled, this signal provides
for monitoring of the internal GX1 core INTR signal for
debug purposes. To enable, pull up FPCI_MON (ball A4).
O System Management Interrupt. This is the input to the
GX1 core. When enabled, this signal provides for monitor-
ing of the internal GX1 core SMI# signal for debug pur-
poses. To enable, pull up FPCI_MON (ball A4).
Type Description
I JTAG Test Clock. This signal has an internal weak pull-up
resistor.
I JTAG Test Data Input. This signal has an internal weak
pull-up resistor.
AMD Geode™ SC1200/SC1201 Processor Data Book
Signal Definitions
Mux
ACK#+TFTDE+
VOPCK
PD7+TFTD13
PD6+TFTD1+
VOPD0
PD5+TFTD11
PD4+TFTD10
PD3+TFTD9
PD2+TFTD8+
VOPD7
PD1+TFTD7+
VOPD6
PD0+TFTD6+
VOPD5
SLCT+TFTD15
PE+TFTD14
BUSY/WAIT#+
TFTD3+VOPD2
ERR#+TFTD4+
VOPD3
STB#/WRITE#+
TFTD17
SLIN#/ASTRB#+
TFTD16
AC97_RST#
GPIO16+
PC_BEEP
SDATA_IN
BIT_CLK
AFD#/DSTRB#+
TFTD2+VOPD1
INIT#+TFTD5+
VOPD4+
