32579B
5.4.2.2 LDN 01h - System Wakeup Control
Table 5-8 lists registers that are relevant to the configura-
tion of System Wakeup Control (SWC). These registers are
Index Type Configuration Register or Action
30h R/W
Activate. When bit 0 is cleared, the registers of this logical device are not accessible.
60h R/W Base Address MSB register.
61h R/W Base Address LSB register. Bits [3:0] (for A[3:0]) are RO, 0000b.
70h R/W Interrupt Number. (For routing the internal PWUREQ signal.)
71h R/W Interrupt Type. Bit 1 is R/W. Other bits are RO.
74h RO Report no DMA assignment.
75h RO Report no DMA assignment.
1. The logical device registers are maintained, and all wakeup detection mechanisms are functional.
100
described earlier in Table 5-3 "Standard Configuration Reg-
isters" on page 95.

Table 5-8. Relevant SWC Registers

AMD Geode™ SC1200/SC1201 Processor Data Book
SuperI/O Module
Reset
Value
1 00h
00h
00h
00h
03h
04h
04h
