32579B
9.3.2 Video Port (VP) Interface
Symbol Parameter
t VPCKIN cycle time
VP_C
t Video Port input setup time before
VP_S
VPCKIN rising edge
t Video Port input hold time after VPCKIN
VP_H
rising edge
t VPCKIN fall/rise time
VPCK_FR
t VPCKIN duty cycle
VPCK_D
Note 1. Guaranteed by characterization.
V
IHD
VPCKIN
V
ILD
t
PCK_FR
VPD[7:0]
380

Table 9-13. Video Input Port Timing Parameters

t
VP_C
t
PCK_FR

Figure 9-6. Video Input Port Timing Diagram

Min Max Unit
18 ns
6 ns
0 ns
- 2 ns
35/65 %
t
VP_S
AMD Geode™ SC1200/SC1201 Processor Data Book
Electrical Specifications
Comments
Note 1
V
REF
t
VP_H
