Signal Definitions
3.4.19 JTAG Interface Signals (Continued)
Signal Name Ball No.
TDO E30
TMS F28
TRST# E29
3.4.20 Test and Measurement Interface Signals
Signal Name Ball No.
GXCLK V30
TEST3 V30
TEST2 AJ1
TEST1 AG4
TEST0 AH3
GTEST F30
PLL6B AG4
PLL5B AJ1
PLL2B AH3
SDTEST5 D28
SDTEST4 C31
SDTEST3 E28
SDTEST2 C28
SDTEST1 B29
SDTEST0 C30
TDP D30
TDN D31
AMD Geode™ SC1200/SC1201 Processor Data Book
Type Description
O JTAG Test Data Output
I JTAG Test Mode Select. This signal has an internal weak
pull-up resistor.
I JTAG Test Reset. This signal has an internal weak pull-up
resistor.
For normal JTAG operation, this signal should be active at
power-up.
If the JTAG interface is not being used, this signal can be
tied low.
Type Description
O GX Clock. This signal is for internal testing only. For nor-
mal operation either program as FP_VDD_ON or leave
unconnected.
O Internal Test Signal. This signal is used for internal test-
ing only. For normal operation leave unconnected, unless
programmed as FP_VDD_ON.
O Internal Test Signals. These signals are used for internal
testing only. For normal operation leave unconnected.
O
O
I Global Test. This signal is used for internal testing only.
For normal operation this signal should be pulled down
with 1.5 KΩ.
I/O PLL6, PLL5 and PLL2 Bypass. These signals are used
for internal testing only and requires additional test modes
I/O
to observe the PLLs. These modes are not described in
I/O
this specification. For normal operation leave uncon-
nected.
O Memory Internal Test Signals. These signals are used
for internal testing only. For normal operation, these sig-
nals should be programmed as one of their muxed
options.
O
O
O
O
O
I/O Thermal Diode Positive / Negative. These signals are for
internal testing only. For normal operation leave uncon-
I/O
nected.
32579B
Mux
---
---
---
Mux
FP_VDD_ON+
TEST3
FP_VDD_ON+
GXCLK
PLL5B
PLL6B
PLL2B
---
TEST1
TEST2
TEST0
GPIO6+
DTR2#/BOUT2+
IDE_IOR1#
GPIO8+CTS2#+
IDE_DREQ1
SIN2
GPIO9+DCD2#+
IDE_IOW1#
GPIO10+DSR2#+
IDE_IORDY1
GPIO7+RTS2#+
IDE_DACK1#
---
---
