6.2.9.2 Sleep States
The SC1200/SC1201 processor supports four Sleep states
(SL1-SL3) and the Soft Off state (G2/S5). These states are
fully compliant with the ACPI specification, revision 1.0.
When the SLP_EN bit (F1BAR1+I/O Offset 0Ch[13]) is set
to 1, the SC1200/SC1201 processor enters an SLx state
according to the SLP_TYPx field (F1BAR1+I/O Offset
0Ch[12:10]). It exits the Sleep state back to the S0 state
(C0 state - Full Speed or Throttling, depending on the
THT_EN bit) upon an enabled power management event.
Table 6-5 on page 159 lists wakeup events from the various
Sleep states.
SL1 Sleep State (ACPI S1)
In this state the core processor is in 3V Suspend mode (all
its clocks are stopped, including the memory controller and
the display controller). The SDRAM is placed in self-refresh
mode. All other SC1200/SC1201 processor system clocks
and PLLs are running. All devices are powered up
(PWRCNT[2:1] and ONCTL# are all asserted). See Sec-
tion 6.2.9.5 "Usage Hints" on page 161.
No reset is performed, when exiting this state. The
SC1200/SC1201 processor keeps all context in this state.
This state corresponds to ACPI Sleep state S1.
SL2 Sleep State (ACPI S1)
In this state, all of the SC1200/SC1201 processor clocks
are stopped including the PLLs. Selected clocks from the
PLLs can be kept running under program control (F0 Index
60h). An exception to this is the CLK32 output signal which
keeps toggling and the 32 KHz oscillator itself. The
SDRAM is placed in self-refresh mode. The PWRCNT1 pin
is de-asserted. The SC1200/SC1201 processor itself is
Event
Enabled Interrupts
SMI according to Table 6-8
SCI according to Table 6-8
GPIO[47:32], GPIO[15:0]
Power Button
Power Button Override
Bus Master Request
Thermal Monitoring
USB
SDATA_IN2 (AC97)
IRRX1 (Infrared)
GPWIO[2:0]
RI2# (UART2)
RTC
1. Temporarily exits state.
AMD Geode™ SC1200/SC1201 Processor Data Book

Table 6-5. Wakeup Events Capability

S0/C1 S0/C3
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes
1
Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
powered up. The system designer can decide which other
system devices to power off with the PWRCNT1 pin.
No reset is performed, when exiting this state. The
SC1200/SC1201 processor keeps all context in this state.
This state corresponds to ACPI sleep state S1, with lower
power and longer wake time than in SL1.
SL3 Sleep State (ACPI S3)
In this state, the SDRAM is placed in self-refresh mode,
and PWRCNT[2:1] are de-asserted. PWRCNT[2:1] should
be used to power off most of the system (except for the
SDRAM). If the Save-to-RAM feature is used, external cir-
cuitry in the SDRAM interface is required to guarantee data
integrity. All SC1200/SC1201 processor signals powered
by V , V or V are still functional to allow wakeup
SB SBL BAT
and to keep the RTC.
The power-up sequence is performed, when exiting this
state. This state corresponds to ACPI Sleep state S3.
SL4 and SL5 Sleep States (ACPI S4 and S5)
The SL4 and SL5 states are similar from the hardware per-
spective. In these states, the SC1200/SC1201 processor
de-asserts PWRCNT[2:1] and ONCTL#. PWRCNT[2:1]
and ONCTL# should be used to power off the system. All
signals powered by V , V
SB SBL
allow wakeup and to keep the RTC.
While in this state, LED# can be toggled to give visual noti-
fication of this state. ACPI Function Control register
(F1BAR1+I/O Offset 07h[7:6]) is used to control LED#.
The power-up sequence is performed when exiting this
state. This state corresponds to ACPI Sleep states S4 and
S5.
SL1 SL2
Yes -
Yes -
Yes -
Yes -
Yes Yes
Yes Yes
Yes -
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
32579B
or V are still functional to
BAT
SL3 SL4, SL5
- -
- -
- -
- -
Yes Yes
Yes Yes
- -
Yes Yes
- -
- -
- -
Yes Yes
- -
Yes Yes
159
