Ball No. Signal
N29 GPIO12
M29 GPIO13
AG1 GPIO18
C11 IRTX
AK8 IRRX1
M28 GPIO32
L31 GPIO33
L30 GPIO34
L29 GPIO35
L28 GPIO36
K31 GPIO37
K28 GPIO38/IRRX2
J31 GPIO39
E28 SIN2
U29 AC97_RST#
U31 SDATA_IN
U30 BIT_CLK
AG4 PLL6B
AJ1 PLL5B
AH3 PLL2B
46
Table 3-5. Two-Signal/Group Multiplexing (Continued)
Default
Configuration
GPIO
PMR[19] = 0
GPIO
PMR[16] = 0
Infrared
PMR[6] = 0
GPIO
PMR[14] = 0 and PMR[22] =
0
UART
PMR[28] = 0
AC97
FPCI_MON = 0
Internal Test
PMR[29] = 0
Alternate
Signal
ACCESS.bus
AB2C PMR[19] = 1
AB2D
UART
DTR1#/BOUT1 PMR[16] = 1
UART
SOUT3 PMR[6] = 1
SIN3
LPC
LAD0 PMR[14] = 1 and PMR[22] =
1
LAD1
LAD2
LAD3
LDRQ#
LFRAME#
LPCPD#
SERIRQ
Internal Test
SDTEST3 PMR[28] = 1
FPCI Monitoring
F_STOP# FPCI_MON = 1
F_GNT0#
F_TRDY#
Internal Test
TEST1 PMR[29] = 1
TEST2
TEST0
