Table 6-27. USB_BAR: USB Controller Registers Summary

USB_BAR0
+Memory Width
Offset (Bits) Type
00h-03h 32 R/W
04h-07h 32 R/W
08h-0Bh 32 R/W
0Ch-0Fh 32 R/W
10h-13h 32 R/W
14h-17h 32 R/W
18h-1Bh 32 R/W
1Ch-1Fh 32 R/W
20h-23h 32 R/W
24h-27h 32 R/W
28h-2Bh 32 R/W
2Ch-2Fh 32 R/W
30h-33h 32 R/W
34h-37h 32 R/W
38h-3Bh 32
3Ch-3Fh 32
40h-43h 32 R/W
44h-47h 32 R/W
48h-4Bh 32 R/W
4Ch-4Fh 32 R/W
50h-53h 32 R/W
54h-57h 32 R/W
58h-5Bh 32 R/W
5Ch-5Fh 32 R/W
60h-9Fh ---
100h-103h 32 R/W
104h-107h 32 R/W
108h-10Dh 32 R/W
10Ch-10Fh 32 R/W
AMD Geode™ SC1200/SC1201 Processor Data Book
Name
HcRevision
HcControl
HcCommandStatus
HcInterruptStatus
HcInterruptEnable
HcInterruptDisable
HcHCCA
HcPeriodCurrentED
HcControlHeadED
HcControlCurrentED
HcBulkHeadED
HcBulkCurrentED
HcDoneHead
HcFmInterval
RO HcFrameRemaining
RO HcFmNumber
HcPeriodicStart
HcLSThreshold
HcRhDescriptorA
HcRhDescriptorB
HcRhStatus
HcRhPortStatus[1]
HcRhPortStatus[2]
HcRhPortStatus[3]
--- Reserved
HceControl
HceInput
HceOutput
HceStatus
32579B
Reference
Reset Value (Table 6-42)
00000110h Page 285
00000000h Page 285
00000000h Page 286
00000000h Page 286
00000000h Page 287
00000000h Page 287
00000000h Page 288
00000000h Page 288
00000000h Page 288
00000000h Page 288
00000000h Page 288
00000000h Page 288
00000000h Page 288
00002EDFh Page 288
00000000h Page 289
00000000h Page 289
00000000h Page 289
00000628h Page 289
01000003h Page 289
00000000h Page 290
00000000h Page 290
00000000h Page 291
00000000h Page 292
00000000h Page 293
xxxxxxxxh Page 294
00000000h Page 295
000000xxh Page 295
000000xxh Page 295
00000000h Page 295
