Signal Definitions
3.4.4 CRT/TFT Interface Signals (Continued)
Signal Name Ball No.
TFTDCK AA1
A10
TFTDE P2
B18
FP_VDD_ON AB1
V30
TFTD[17:0] See
Table 3-3
on page
40
AMD Geode™ SC1200/SC1201 Processor Data Book
Type Description
O TFT Clock. Clock to external CRT DACs or TFT.
O TFT Data Enable. Can be used as blank signal to exter-
nal CRT DACs.
O TFT Power Control. Used to enable power to the Flat
Panel display, with power sequence timing.
O Digital RGB Data to TFT.
TFTD[5:0] - Connect to BLUE TFT inputs.
TFTD[11:6] - Connect to GREEN TFT inputs.
TFTD[17:12] - Connect to RED TFT inputs.
32579B
Mux
IDE_RST#
GPIO17+ IOCS0#
IDE_CS1#
ACK#+VOPCK+
FPCICLK
IDE_DATA4
GXCLK+TEST3
The TFT interface is
muxed with the IDE
interface or the Par-
allel Port/VOP inter-
face. See Table 3-5
on page 45 and
Table 3-7 on page
48 for details.
