Chapter 31 - VRRP Commands

VRRP or Virtual Routing Redundancy Protocol is a function on the Switch that dynamically assigns responsibility for a virtual router to one of the VRRP routers
on a LAN.The VRRP router that controls the IP address associated with a virtual router is called the Master, and will forward packets sent to this IP address.This
will allow any Virtual Router IP address on the LAN to be used as the default first hop router by end hosts. Utilizing VRRP, the administrator can achieve a higher
available default path cost without needing to configure every end host for dynamic routing or routing discovery protocols.
Statically configured default routes on the LAN are prone to a single point of failure.VRRP is designed to eliminate these failures by setting an election protocol
that will assign a responsibility for a virtual router to one of the VRRP routers on the LAN.When a virtual router fails, the election protocol will select a virtual
router with the highest priority to be the Master router on the LAN.This retains the link and the connection is kept alive, regardless of the point of failure.
To configure VRRP for virtual routers on the Switch, an IP interface must be present on the system and it must be a part of a VLAN.VRRP IP interfaces may be
assigned to every VLAN, and therefore IP interface, on the Switch.VRRP routers within the same VRRP group must be consistent in configuration settings for this
protocol to function optimally.
The VRRP commands in the Command Line Interface (CLI) are listed, along with the appropriate parameters, in the following table.
Command
enable vrrp
disable vrrp
create vrrp vrid
config vrrp vrid
config vrrp ipif
show vrrp
delete vrrp
Each command is listed, in detail, in the following sections:
enable vrrp
Purpose
Syntax
Description
Parameters
Restrictions
Example usage:
To enable VRRP globally on the Switch:
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
Parameters
{ping}
{ping}
<vrid 1-255> <ipif_name 12> ipaddress <ipaddr> {state [enable | disable] | priority <int 1-254> |
advertisement_interval <int 1-255> | preempt [true | false] | critical_ip <ipaddr> | critical_ip_state [enable |
disable]}
<vrid 1-255> {state [enable | disable] | priority <int 1-254> | ipaddress <ipaddr> | advertisement_interval <int
1-255> | preempt [true | false] | critical_ip <ipaddr> | critical_ip_state [enable | disable]}
<ipif_name 12> [authtype [none | simple authdata <string 8> | ip authdata <string 16>]]
{ipif <ipif_name 12> {vrid <vrid 1-255>}
{ipif <ipif_name 12> vrid <vrid 1-255>}
To enable a VRRP interface configuration.
enable vrrp {ping}
This command will enable the VRRP interface configuration on the Switch.
{ping} – Adding this parameter to the command will allow the virtual IP address to be pinged from other host
end nodes to verify connectivity.This will only enable the ping connectivity check function.To enable the VRRP
protocol on the Switch, omit this parameter.This command is disabled by default.
Only administrator-level users can issue this command.
AT-9724TS:4# enable vrrp
Command: enable vrrp
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
