Server
Switch
Supplied cable
Figure 13 Connecting to a dedicated backup network

Powering on the HP D2D

Press the Power on button on the front of your HP D2D Backup System. The normal boot sequence
takes approximately 2 minutes. On power up the HP D2D Backup System runs its fans at high speed
for approximately 10 seconds before returning to normal speed.
Figure 14 Powering on the HP D2D Backup System
1. Power On button
Software installation, discovery and configuration
There are three stages to installation:
• Install all the required drivers
• Discover the HP D2D Backup System on the network and configure network settings, if required
• Install an iSCSI Initiator, if required, and set up the iSCSI base configuration
UNIX and Linux users should download the latest patches for their operating system and refer to the
"UNIX Configuration Guide" on the HP StorageWorks CD-ROM for configuration instructions.

Installation wizard for Windows users

For Windows users, the recommended way to set up the HP D2D Backup System network is to run the
Installation wizard from the HP StorageWorks CD-ROM, particularly if you are configuring the host
for the first time.
32
Connecting and installing the HP D2D Backup System
Server Server
LAN
Storage Network
HP StorageWorks D2D
Backup System
