Page 1: Hp Smart Array P400 Controller
HP Smart Array P400 Controller User Guide October 2005 (First Edition) Part Number 399716-001... - Page 2 © Copyright 2005 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
-
Page 3: Table Of Contents
Contents Hardware features ........................5 Board components ............................ 5 SAS/SATA connectors on the front of the board .................. 5 SAS/SATA connectors on the back of the board.................. 6 Controller specifications ..........................6 Overview of the installation procedure .................... 8 Installing the controller in an unconfigured server ..................8 Installing the controller in a previously configured server ................ - Page 4 Upgrading hard drive capacity ....................... 29 Moving drives and arrays ........................30 Adding drives ............................30 Diagnosing array problems......................32 Controller board runtime LEDs........................32 Battery pack LEDs............................ 33 Diagnostic tools ............................34 Electrostatic discharge ......................... 36 Preventing electrostatic discharge ......................36 Grounding methods to prevent electrostatic discharge ..................
-
Page 5: Hardware Features
Hardware features In this section Board components ........................... 5 Controller specifications ..........................6 Board components Two models of the HP Smart Array P400 Controller are available. One model ("SAS/SATA connectors on the front of the board" on page 5) has the internal SAS/SATA connectors on the front of the board, while the other model ("SAS/SATA connectors on the back of the board"... -
Page 6: Sas/Sata Connectors On The Back Of The Board
SAS/SATA connectors on the back of the board Item ID Description Connectors for the cache module (also known as BBWC or array accelerator). SAS or SATA port 1I (internal), 4x wide SFF8484 connector. Runtime LEDs. To interpret the illumination pattern of these LEDs, see "Controller board runtime LEDs (on page 32)". - Page 7 Time required to recharge From 15 minutes to two hours, depending on the initial battery charge battery level Duration of battery backup More than two days if the battery is fully-charged and less than three years old Battery life expectancy More than three years Type of edge connector PCIe x8 (fits in slots that have a physical size of x8 or greater;...
-
Page 8: Overview Of The Installation Procedure
Overview of the installation procedure In this section Installing the controller in an unconfigured server ..................8 Installing the controller in a previously configured server ................8 Installing the controller in an unconfigured server New HP ProLiant server models self-configure when they are powered up for the first time. For more information about the autoconfiguration process, refer to the server-specific setup and installation guide or the HP ROM-Based Setup Utility User Guide. - Page 9 Update the Management Agents ("Installing Management Agents" on page 19) if new versions are available. The server is now ready to use. If you want to create additional logical drives, you may now do so. Overview of the installation procedure 9...
-
Page 10: Installing The Controller Hardware
Installing the controller hardware In this section Before beginning the installation ......................10 Preparing the server ..........................10 Installing the controller board ........................10 Connecting storage devices........................11 Before beginning the installation Before beginning the installation procedure, visit the HP website (http://www.hp.com/support) to confirm that you have the latest version of each driver and utility file needed. -
Page 11: Connecting Storage Devices
Slide the controller board along the slot alignment guide if applicable, and press the board firmly into the slot so that the contacts on the board edge are properly seated in the system board connector. Secure the controller board in place with the retaining screw. If there is a guide latch on the rear of the board, close the latch. -
Page 12: Updating The Firmware
Updating the firmware In this section Methods for updating the firmware......................12 Methods for updating the firmware To update the firmware on the server, controller, or hard drives, use Smart Components. These components are available on the Firmware Maintenance CD. A more recent version of a particular server or controller component might be available on the support page of the HP website (http://www.hp.com/support). -
Page 13: Configuring An Array
Configuring an array In this section Introduction ............................13 Comparing the utilities ..........................13 Using ORCA............................14 Using ACU ............................15 Using CPQONLIN..........................15 Introduction HP provides four utilities for manually configuring an array on a Smart Array controller: ORCA—A simple ROM-based configuration utility ACU—A versatile, browser-based utility that provides maximum control over configuration parameters ACU CLI—A command line version of ACU... -
Page 14: Using Orca
Supported features CPQONLIN ORCA Uses a wizard to suggest the optimum configuration for an unconfigured controller Describes configuration errors Supported procedures CPQONLIN ORCA Creation and deletion of arrays and logical drives Assignment of RAID level Sharing of spare drives among several arrays Assignment of multiple spare drives per array Setting of stripe size Migration of RAID level or stripe size... -
Page 15: Using Acu
NOTE: You cannot use ORCA to configure one spare drive to be shared among several arrays. Only ACU enables you to configure shared spare drives. Press the Enter key to accept the settings. Press the F8 key to confirm the settings and save the new configuration. After several seconds, the Configuration Saved screen appears. -
Page 16: Expanding An Array
Select the Controller Settings option below Controller Options. The Controller Settings screen appears. Drive rebuild Drive rebuild occurs after a physical drive fails and is replaced. Only logical drives that are configured with RAID 1+0, RAID 5, or RAID 6 (ADG) can be rebuilt. Priority settings To set the drive rebuild priority: Highlight the controller. -
Page 17: Migrating Raid Level And Stripe Size Online
Migrating RAID level and stripe size online Using CPQONLIN, you can modify both the RAID level and stripe size of an existing logical drive while online. IMPORTANT: Be sure that the cache battery is connected and fully charged before beginning an array expansion, RAID level migration, or stripe size migration. -
Page 18: Setting The Boot Controller And Controller Order
Setting the boot controller and controller order In this section Setting a controller as the boot controller ....................18 Setting the controller order ........................18 Setting a controller as the boot controller The following procedure enables you only to set a controller as the boot controller. If you also want to adjust the boot order settings of other controllers in the system, use RBSU instead ("Setting the controller order"... -
Page 19: Installing Device Drivers And Management Agents
Installing device drivers and Management Agents In this section Installing device drivers........................... 19 Installing Management Agents ......................... 19 Installing device drivers The drivers for the controller are located on the Support Software CD or the SmartStart CD that is provided in the controller kit. Updates are posted to the HP website (http://www.hp.com/support). Using the Support Software CD: Instructions for installing the drivers from the Support Software CD are given in the leaflet that is supplied with the CD. -
Page 20: Upgrading Or Replacing Controller Options
Upgrading or replacing controller options In this section Installing or replacing a battery........................ 20 Upgrading the cache ..........................22 Installing or replacing a battery The procedure for replacing an existing cache battery ("Replacing a battery" on page 21) is different from the procedure for installing a battery into a server that does not have one ("Installing a battery"... -
Page 21: Replacing A Battery
Plug the other end of the battery cable into the connector on the cache module. NOTE: Your model might look different from the one illustrated. NOTE: After installing a battery pack, you might see a POST message during reboot indicating that the array accelerator (cache) is temporarily disabled. -
Page 22: Upgrading The Cache
Remove the battery pack from the server. Plug the cable into the new battery pack. Install the new battery pack into the server. Verify that the other end of the cable is properly seated in the cache connector. NOTE: After installing a battery pack, you might see a POST message during reboot indicating that the array accelerator (cache) is temporarily disabled. - Page 23 If the LED is not lit, disconnect the battery cable from the cache. NOTE: Your model might look different from the one illustrated. Remove the controller from the server, and place it on a firm, flat, nonconducting surface. Remove the existing cache from the controller, pulling at both ends of the cache module with equal force.
-
Page 24: Replacing, Moving, Or Adding Hard Drives
Replacing, moving, or adding hard drives In this section Identifying the status of a hard drive ......................24 Recognizing hard drive failure ......................... 25 Replacing hard drives ..........................27 Moving drives and arrays ........................30 Adding drives ............................30 Identifying the status of a hard drive When a drive is configured as a part of an array and connected to a powered-up controller, the condition of the drive can be determined from the illumination pattern of the hard drive status lights (LEDs). -
Page 25: Recognizing Hard Drive Failure
Online/Activity Fault/UID LED Interpretation LED (green) (amber/blue) The drive is online, but it is not active currently. Flashing regularly Amber, flashing Do not remove the drive. Removing a drive may (1 Hz) regularly (1 Hz) terminate the current operation and cause data loss. The drive is part of an array that is undergoing capacity expansion or stripe migration, but a predictive failure alert has been received for this drive. -
Page 26: Effects Of A Hard Drive Failure
Effects of a hard drive failure When a hard drive fails, all logical drives that are in the same array are affected. Each logical drive in an array might be using a different fault-tolerance method, so each logical drive can be affected differently. -
Page 27: Replacing Hard Drives
Replacing hard drives The most common reason for replacing a hard drive is that it has failed. However, another reason is to gradually increase the storage capacity of the entire system. If you insert a hot-pluggable drive into a drive bay while the system power is on, all disk activity in the array pauses for a second or two while the new drive is spinning up. - Page 28 drive) and write it to the replacement drive. This process is called automatic data recovery, or rebuild. If fault tolerance is compromised, this data cannot be reconstructed and is likely to be permanently lost. If another drive in the array fails while fault tolerance is unavailable during rebuild, a fatal system error can occur, and all data on the array is then lost.
-
Page 29: Upgrading Hard Drive Capacity
Back up as much data as possible from the logical drive. CAUTION: Do not remove the drive that has the media error. Doing so causes the logical drive to fail. Restore data from backup. Writing data to the location of the unreadable sector often eliminates the error. -
Page 30: Moving Drives And Arrays
Repeat the previous step for the other drives in the array, one at a time. When you have replaced all drives, you can use the extra capacity to either create new logical drives or extend existing logical drives. For more information about these procedures, refer to the HP Array Configuration Utility User Guide. - Page 31 physical drives in the array. During this procedure, the logical drives each keep the same fault-tolerance method in the enlarged array that they had in the smaller array. When the expansion process has finished, you can use the liberated storage capacity on the enlarged array to create new logical drives.
-
Page 32: Diagnosing Array Problems
Diagnosing array problems In this section Controller board runtime LEDs........................32 Battery pack LEDs........................... 33 Diagnostic tools ............................. 34 Controller board runtime LEDs NOTE: During server power-up, each runtime LED illuminates randomly until POST has finished. LED ID Color LED name and interpretation Amber CR14: Controller Lockup LED. -
Page 33: Battery Pack Leds
Controller CPU activity level Item 7 status Item 8 status 0–25% Blinking 25–50% Blinking 50–75% On steadily 75–100% On steadily On steadily Battery pack LEDs Item ID Color Description Green System Power LED. This LED glows steadily when the system is powered up and 12 V system power is available. -
Page 34: Diagnostic Tools
LED3 pattern LED4 pattern Interpretation One blink every The system is powered down, and the cache contains data that has two seconds not yet been written to the drives. Restore system power as soon as possible to prevent data loss. Data preservation time is extended any time that 3.3 V auxiliary power is available, as indicated by LED 2. - Page 35 Click Server Diagnostics, and follow the on-screen prompts and instructions. Diagnosing array problems 35...
-
Page 36: Electrostatic Discharge
Electrostatic discharge In this section Preventing electrostatic discharge......................36 Grounding methods to prevent electrostatic discharge ................36 Preventing electrostatic discharge To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices. -
Page 37: Regulatory Compliance Notices
EMC Directive 89/336/EEC Compliance with these directives implies conformity to applicable harmonized European standards (European Norms) which are listed on the EU Declaration of Conformity issued by Hewlett-Packard for this product or product family. This compliance is indicated by the following conformity marking placed on the product: This marking is valid for non-Telecom products and EU harmonized Telecom products (e.g. -
Page 38: Korean Class B Notice
Korean class B notice Battery replacement notice This component uses a nickel metal hydride (NiMH) battery pack. WARNING: There is a risk of explosion, fire, or personal injury if a battery pack is mishandled. To reduce this risk: Do not attempt to recharge the batteries if they are disconnected from the controller. Do not expose the battery pack to water, or to temperatures higher than 60°C (140°F). -
Page 39: Acronyms And Abbreviations
Acronyms and abbreviations Array Configuration Replicator Array Configuration Utility Advanced Data Guarding (also known as RAID 6) Array Diagnostics Utility BBWC battery-backed write cache CPQONLIN NetWare Online Array Configuration Utility ORCA Option ROM Configuration for Arrays POST Power-On Self Test RBSU ROM-Based Setup Utility Smart Array... -
Page 40: Index
Index drives, moving 30 ACU (Array Configuration Utility) 15 adding drives 16, 30 electrostatic discharge 36 ADU (Array Diagnostic Utility) 34 environmental requirements 6 array capacity expansion 30 error messages 25, 34 array controller installation overview 8 European Union notice 37 array, configuring 13, 16 expanding an array 30 array, moving 30... - Page 41 ORCA (Option ROM Configuration for Arrays) 14 overview of installation process 8 POST error messages 25, 34 power requirements 6 preparation procedures 10 rebuild, abnormal termination of 28 rebuild, description of 27 rebuild, time required for 28 regulatory compliance notices 37 replacing hard drives 24 replacing the batteries 20 ROM, updating 12...
