1 Before you start

In this chapter:
• "Overview" on page 15
• "Optional tape
• "Software and hardware
• "Terminology" on page 17
• "Storage
capacity" on page 20
• "Data deduplication" on page 21

Overview

The HP StorageWorks D2D Backup System is an iSCSI or Fibre Channel disk-based storage appliance
that emulates up to 16 tape devices, which can be used to back up host network servers or PCs. Each
tape device is configured as an Ultrium Tape Library or Autoloader. An emulation type is selected during
initial configuration and this determines the maximum number of drives and the maximum number of
slots that may be configured for the device. The default configuration emulates the HP StorageWorks
MSL2024 Tape Library, which provides a loader with one drive and 24 slots.
1. Power On button/LED
2. Hot plug drives
3. HP D2D Beacon LED
4. System Health LED
Figure 1 Front view of the HP D2D Backup System
attach" on page 16
requirements" on page 16
5. LAN Port 1 LED
6. LAN Port 2 LED
7. Disk Online LED
8. Disk Beacon LED
D2D Backup SystemHP D2D4004 and HP D2D4009
