2.
Connect the keyboard cable to the PS/2 ports on the rear of the unit. Do not connect anything to
the USB ports.
Figure 24 System console connections on the HP D2D
1 and 2. PS/2 ports for system console keyboard and mouse
3. VGA port for system console monitor
3.
Power on the HP D2D and allow it to boot up until the console screen is displayed (see example
below). Select the Network... option from the left-hand Menu.
48
Advanced installation
