Server
Supplied cable
Figure 14 Connecting to a dedicated backup network

Powering on the HP D2D

NOTE:
If you have installed the Capacity Upgrade Kit, power it on first. You may need to hold down the
power on button (on the rear of the unit) for a few seconds.
Press the Power on button on the front of your HP D2D Backup System. The normal boot sequence
takes approximately 2 minutes. On power up the HP D2D Backup System runs its fans at high speed
for approximately 10 seconds before returning to normal speed.
Figure 15 Powering on the HP D2D Backup System
1. Power On button

Software installation, discovery and configuration

There are three stages to installation:
• Install all the required drivers
• Discover and configure the HP D2D Backup System on the network
Server
Switch
Storage Network
HP StorageWorks D2D
Backup System
Server
LAN
D2D Backup System HP D2D4112 39
