R 3 Intel NetStructure™ 470T and 470F Switches User Guide

Installing a New Device

After you've installed a new switch on your network, you can use Intel
Device View's Device Install Wizard to configure it for management.
To install and configure a new switch for
management
1 Start Intel Device View. The Device Install Wizard appears. If it
doesn't appear, click Install from the Device menu or double-click the
appropriate MAC address in the Device Tree under Unconfigured
Devices. (The MAC address is located on the rear of the switch.)
2 On the Device Install Wizard - Start screen, click Next.
3 On the Device Install Wizard - MAC Address screen, click the MAC
address of the new switch and then click Next.
4 Follow the instructions in the wizard to assign an IP address and a name
to the switch.
