I N D E
setting for optional module 52
fragments 95
frames
broadcast 97
tagged 10
unicast 97
viewing for individual ports 94
G - J
gateway, default 50
general information
viewing using Local Management 53
viewing using Web Device Manager 42
GVRP 80
configuring 37, 90
description 15
status 91, 101
Head of Line (HOL) blocking prevention 54
High Priority Service Ratio 54
hot keys, using 47
HyperTerminal, default parameters 45
IEEE 802.1p priority tags, description 10
IEEE 802.1Q VLAN. See tag-based VLAN
IGMP, description 16, 59
IGMP snooping
configuring 59
on VLAN 59, 81, 82
status 98
in-band connection through Telnet 46
ingress filter 90
ingress filtering 36, 37, 83, 87
Intel Device View
installing 18
installing a new switch 23
overview 17
starting 19
IP address 29
assigning remotely (BOOTP/DHCP) 50
configuring 29
default 26
subnet mask 50
IP Settings screen 29
jabber 95
